Q35Y Series

Hydraulic Ironworker Machine

Product Description

DURMAPRESS®The hydraulic profile steel shears of the Q35Y series cut and punch flat steel, bars and profiles extremely precisely and efficiently. Section steel shears like these are mainly used in locksmiths' shops, repair shops and in vehicle construction. As one- or two-cylinder, the construction impresses with its multifunctionality. It combines flat steel shears, notchers, hole punches and profile steel shears in one machine. The punching machine of the Q35Y series works with common punches and dies, which extends the range of applications of the machines.

Product Details

Flat Steel Cutters

• For strip steel, flat steel, wide flat steel
• Table with angular and linear stops
• Adjustable hold-down
• Lower knife provides 4 cutting edges

Angular Profile Steel Cutters

• For angle steel sections
• Cut angle 90° and 45°
• Adjustable material guide plate

Rod Steel Station

• For round and square steel
• Robust material guide plate

Back Gauge

• Including swivel boom
• For use on Flat Steel, Angular Steel and Rod Steel Stations

Hole Punch Station

• For punching round holes and slots in sheet metals, flat steel and U-Section steel
• Table with adjustable angular stops
• Infinitely variable stroke adjustment
• Premium Kingsland tools
• Hydraulic overload protection

Notching Station

• Rigid support table with adjustable stops

Over 15 Years Of Experience In Top Level Controls

Hydraulic Ironworker Description

In the past, you might need to buy a punching machine, shears, press brake, profile cutting machine and notching machine to complete the processing of various workpieces. But now it is not needed, you only need a hydraulic ironworker machine to complete all the above processing. Is it hard to imagine? Then we will introduce you to the DURMAPRESS® Iron Worker.

“Safety” has always been the most important for DURMAPRESS®. We have always been committed to the safety of the machine. So, the emergency stop switch is installed in the electrical cabinet and stations of the machine.

In an emergency, you can stop the machine at any time to prevent accidents. At the same time, the safety point is installed in the notching station. for instance，If you open the safety shield for non-safe operation, the machine does not work.

CE certification guarantees the strict quality and safety standards of the machine.

DURMAPRESS Siemens Main Motor

Compared to traditional stepper motors, the advantages of using servo motors include: improve the accuracy to ± 0.01mm, the noise decrease to 25 decibels, reduce energy consumption by 60%, consump 70% less hydraulic oil and 30% higher efficiency.

SDKELI Lazer Safe

The sensor can be used alone with the bending machine system. 3 laser beams corresponds to 6 0SSDoutputs, and each laser beam can provide two ways of independent safety output, and the output form isPNP.
lt is in ON state during light transmitting to output a high level; during light shading, it is in OFF state tooutput a low level.After removing the light shading object, osSD will automatically enter the ON state.

Product features ：

•As a Class 1 laser product, it is safe to human eyes;

•L-type protection beam is set up near the upper die tip on the bending machine, and the beam should move in parallel to the upper die tip;
•lt provides a complete functional design to meet the safety protection requirements of bending machinefor processing parts in different shapes;
•lt has a independent controller system, which is also applicable to the bending machine without editingability;
. •lts has a high anti-electromagnetic interference, light interference ability.

Press Brake X-Axis NC BackGauge

Manual R axis

DURMAPRESS® NC Press Brake Successfully controlling precision & productivity, modern sheet metal production is inconceivable without high performance software. Highly effective control algorithms optimize the machine cycle, reduce the time required for set-up and ensures consistently high quality.

Kacon Foot Switch

The Kacon HRF-HD3N medium duty foot switch has a 1 NO + 1 NC contact arrangement with momentary operation and a die cast aluminum housing. Features integrated Z type micro switch. Rated IP 65. Operation: The pedal is held down to power the switch on, and released to turn off.

Specifications

• Switch Dimensions- 100mm W x 211mm L x 125mm H
• Foot Switch Operation- Momentary
• Contact Arrangement- 1 NO + 1 NC
• Rated Current- 15A, 250V AC
• Integrated Switch- Z Type Micro Switch (CE Certified)
• Housing Material- Die Cast Aluminum
• Cable- 1/2" Tap Flexible Cable (Zinc connector 10-16)
• Ingress Protection- IP 65
• Approvals- UL & CUL Recognized, CE

DURMAPRESS X-axis Stepper Motor

X axis is driven by stepper motor andinverter with high positioning accuracy,unique designed synchronous trans-mission mechanism, reliable and stable.

Durmapress ® Quick Clamp System

Advantage:

• Safe and fast tool change
• Can be used without modifying Europe type punches
• Front clamp - vertical tool change
• Rear clamp - horizontal tool change

Flat Steel Cutting

Positioning ruler on the worktable can control the cutting shape and cutting length with higher accuracy
Machine can cut small flat sheets , this function can be used as shearing machine .

Channel Steel Cutting

The quantity and size of the round or square holes can be customized according to customer' s requirements .
lt share the same working position with roundand square cutting function

Angle Steel Cutting

Machine can cut any size of angle steel whose length is smaller than its Max. capacity
Hydraulic Angle steel fixing device is optional.

DURMAPRESS ® Press Brake Toolings

Stress Analysis & Finite Element Analysis

DURMAPRESS ® Press Brake is a machine pressing tool for bending sheet and plate material, most commonly sheet metal. It forms predetermined bends by clamping the workpiece between a matching punch and die. Tooling tolerances should be checked each time a punch and die are selected. It is the operator’s responsibility to ensure the tooling fitrs the manufacturer’s specifications, as well as making any adjustments necessary.

DURMAPRESS Economic Smart Series

Includes Following Features And Properties

Less Waste, Less Maintenance

High Performances

Same Job, 50% Less Energy

High Dynamic Y-axis Control

Over 30% higher productivity

Technical Parameter

Model	Unit	Q35Y-16	Q35Y-20	Q35Y-25	Q35Y-30	Q35Y-40
Pressure	T	60	90	120	160	200
Max.Cutting Thickness of steel plates	mm	16	20	25	30	40
Plate strength	N/mm²	450	450	450	450	450
Angle of Shear	°	7	8	8	8	8
Shearing size of one stroke	mm	16250 8400	20330 10480	25330 16600	20335 20600	40335 30600
Ram stroke	mm	80	80	80	80	100
Number of strokes	Times/min	11-20	12-20	8-18	6-16	6-16
Throat depth	mm	300	355	400	600	530
Punching Thickness	mm	16	20	25	28	35
Max. Punching Diameter	mm	25	30	32	38	45
Main Motor Power	KW	5.5	7.5	11	15	18.5
Overall Dimensions (LWH)	mm	17408101830	19509001950	23559602090	280010502450	290011502550

Components

Name	Details	Manufacturer	Remarks
Valve Block	•Open loop	Rexroth
Back gauge	•X axis	Durmapress	Optional
Oil pump	•Sunny oil pump	Sunny
Main power system	•AC motor	Siemens
Wind-Cooler for Oil	•China	Durmapress
Wind-Cooler for Oil	•Single rail movable type	Durmapress	Optional
Electric	•Schneider Relay	Schneider	Open door power protection
Foot switch	•Korean Kaikun vertical switch
Sealing Ring	•Parker	USA
Oil Pipe Connector	•High Pressure Hose	Durmapress
Security	• Side (Guardrail) + Rear (Guardrail)	Durmapress
	• Side (Guardrail ) + Rear (Guardrail)
	• Side (Guardrail ) + Rear (Guardrail)
Backguage	• 1000mm automatic back gauge for controlling the cutting length of sheet plate and profile steel.	Durmapress	Optional
Controller	•ESTUN E21	ESTUN,CHINA	Optional

Different Profile Cutting Size

Profile	Round Bar	Square Bar	Equal Angle		T Bar		Joist	Channel
Profile	Round Bar	Square Bar	90°Shear	45°Shear	90° Shear	45°Shear	Joist	Channel
Q35Y-16	45	40x40	120x120x12	50x50x5	125x125x12	60x60x8	120x74x5	120x53X5.5
Q35Y-20	50	50x50	140x140x12	70x70x10	140x140x12	70x70x10	160x88x6	160x63X6.5
Q35Y-25	60	50x50	160x160x14	60x60x6	160x160x14	80x80x10	200x102x9	200x75X9
Q35Y-30	65	55x55	180x180x16	80x80x8	180x180x16	80x80x10	280x124x10.5	280x86X11.5
Q35Y-40	70	60x60	200x200x16	80x80x10	200x200x18	100x100x10	300x130x13	300x89X11.5
