XF-7 cantilever CNC cutting machine-Optional cutting mode

XF-7 cantilever CNC cutting machine

(Optional cutting mode: single flame cutting, single plasma cutting or flame plasma dual-use cutting)

XF-7 cantilever CNC cutting machine is a computerized control, fine mechanical transmission, oxygen and gas (propane or acetylene) cutting three technology combination of rate, reliability of hot cutting equipment. Programmable cutting line and arc composition of arbitrary plane shape steel plate parts, the series of CNC cutting machine overall appearance is beautiful, reasonable structure, with good rigidity, high precision, small inertia, smooth work, can be moved at will, does not occupy a fixed site characteristics.

I. Product features:

1. The walking part adopts the non-clearance gear and rack drive, and the motor drive adopts the German Bagra drive technology;

2, Longitudinal guide rail adopts Taiwan imported linear guide rail, high precision, stable operation;

3, The beam adopts special industrial profiles, light weight, no deformation;

5, control system full Chinese interface, easy to operate, U disk import CAD graphics directly cut, no programming, easy to use, stable and reliable;

6. Simple compilation in CAD environment, can achieve simple nesting, automatic sorting, slit compensation and other cutting functions, save time and material, and effectively save cutting nozzle and consumables.

II. Main technical parameters of equipment

model    XF-7

Gauge (mm)

2200 (can be widened according to customer requirements)Rail length (mm)

4500 (can be extended according to customer request)

Effective cutting width (mm)

1650

Effective cutting length (mm)

3500

Speed control range (mm/min)

0-5000.

Lateral and longitudinal drive system

Stepper motor

Number of cutting torch systems (group)

Single flame or single plasma (optional)

Flame cutting thickness

5-180.

Plasma cutting thickness

It is determined by the plasma power supply selected by the user

Flame cutting gas

Oxygen + acetylene/propane/natural gas/gas

Control system

Beijing Starter 2012AH

Plasma power supply

Domestic or imported (optional)
