BS-T SERIES
Tube FIBER LASER CUTTING MACHINE
Designed to Deliver Clean, Consistent Tube Cuts.
Более 5000 производителей по всему миру доверяют нам
Обзор продукта
Разработано для обеспечения точности, эффективности и надежности в условиях современного производства.
Революционная технология резки
Our High-Precision Tube Fiber Laser Cutting Machine represents the latest in industrial cutting technology, designed for metal fabrication and machinery manufacturing.
Передовые технические характеристики
- Dedicated Tube Cutting – Optimized for high-precision tube processing
- Stable Auto Centering – Accurate positioning and cutting
- Fast & Reliable Operation – High rigidity and smooth motion
- Intelligent CNC Control – Consistent cutting quality with easy operation
- Flexible Tube Compatibility – Supports round, square, rectangular, and special-shaped tubes
- Extended Processing Lengths – 6 m and 12 m options for diverse production needs
- Efficient Clamping System – Reduced setup time and improved productivity
Циклы между техническим обслуживанием
0
+
Энергоэффективность
0
%
Быстрее
0
%
Сокращенный цикл
0
%
Детальное проектирование и компоненты
Ознакомьтесь с высокоточными инженерными решениями, лежащими в основе наших систем лазерной резки волоконным лазером серии BS-E.
Laser Chuck
Since the cylinder is uesd to clamp the workpiece directly,the cylinder working stroke is the chunk working stroke,and the clamping range is wide. With direct cylinder output, the output force is linearly proportional to the air presssure,which is easy to implement software control.
Laser Cutting Head
Lightweight and impact-resistant, designed for medium- and low-power lasers. Built-in intelligent sensors enable real-time monitoring, rapid diagnostics, and stable, efficient cutting.
Контроллер
High-end intelligent EtherCAT bus controller designed for high power fiber laser above 8kw.featured by out of box service, easy to install and adjust, full solution
functions,supports custom, automatic and digitization solutions.
Automatic Mechanical Loading System (Option)
The automatic loading system ensures correct tube orientation, precise length positioning, and efficient bundle loading. It supports round, oval, and square tubes up to 120 kg, with fast loading times of ≤ 70 seconds for the first load and ≤ 20 seconds for subsequent loads.
Cypnest Software (Option)
CypNest is a nesting software for CypCut/HypCut laser cutting systems, integrating drawing editing, fast nesting, toolpath generation, and production analysis to improve cutting efficiency and meet diverse production needs.
Режущая головка
Customize The Cutting Head For Your BS-E Series
PRECITEC (Option)
Laser cutting head in solid state, high power Precitec PROCUTTER, with capacitive sensor for tracking metallic surfaces and support for focal lens 200mm, with cartridge glass protection
Источник лазерного излучения
Customize The Laser Source For Your BS-E Series
- Supports faster cutting speeds and efficient processing of thick and hard materials.
- Delivers consistent output with reduced downtime and maintenance needs.
- Suitable for metals, plastics, ceramics, and composite materials across various industries.
- Ensures accurate cutting with fine details and tight tolerances.
Heavy-duty Tube Laser Cutting Machine with Three Chucks
- High in cutting ability
- Cut with 0 tailing
- Высокоточная резка
- Need less costs of production
Tube Fiber Laser Cutting Machine With Auto-loading System
- High Structural Accuracy & Stability
- Enhanced Cutting Precision
- Fully Automatic Alignment
- High-Efficiency Center Positioning
Технические характеристики
Разработано для обеспечения исключительной производительности при решении широкого спектра производственных задач.
| Модель | BS-12550T | BS-60220T | BS-60350T | BS-80350T |
|---|---|---|---|---|
| Tube Range (Length) | 12000mm | 6000mm | 6000mm | 8000mm |
| Мощность лазера | 2KW, 3KW, 6KW, 8KW, 12KW | 2KW, 3KW, 6KW, 8KW, 12KW | 2KW, 3KW, 6KW, 8KW, 12KW | 2KW, 3KW, 6KW, 8KW, 12KW |
| Tube Diameter | 550mm | 220mm | 350 мм | 350 мм |
| X- axis Positioning accuracy | ±0.03 mm/1000 mm | ±0.03 mm/1000 mm | ±0.03 mm/1000 mm | ±0.03 mm/1000 mm |
| Y- axis Positioning accuracy | ±0.03 mm | ±0.03 mm | ±0.03 mm | ±0.03 mm |
| X,Y- axis max positioning speed | 100 м/мин | 100 м/мин | 100 м/мин | 100 м/мин |
| Max accelerated speed | 1.0G | 1.0G | 1.0G | 1.0G |
| Voltage | 380V 50HZ 3PH | 380V 50HZ 3PH | 380V 50HZ 3PH | 380V 50HZ 3PH |
| Graphic format supported | CAD. DXF (etc) | CAD. DXF (etc) | CAD. DXF (etc) | CAD. DXF (etc) |
| Working environment | Temp: 0-40℃, humidity: ≤80% No condensation |
Temp: 0-40℃, humidity: ≤80% No condensation |
Temp: 0-40℃, humidity: ≤80% No condensation |
Temp: 0-40℃, humidity: ≤80% No condensation |
Для получения полных технических характеристик и информации о вариантах индивидуальной конфигурации
Operational Efficiency Metrics
24181260
2000150010005000
Power Consumption (kWh/h)
Maintenance Interval (hours)
Power consumption and recommended maintenance intervals for different power configurations. Higher power models have longer maintenance intervals despite higher energy consumption.
Why Choose us
Эффективность
Maximize productivity with high-speed cutting and minimized downtime
Reliability
Built with premium components for consistent performance in demanding environments
Support
Comprehensive global service network providing technical assistance and training
Смотреть видео
Производитель современного оборудования для обработки металла
Приложения
They are versatile and can be used across a wide range of materials
Бытовая техника
Судостроение
Кухонные принадлежности
Металлообработка
Медицинское оборудование
Автомобилестроение
Готовы преобразить процессы обработки металла?
Получите индивидуальный расчет стоимости с учетом ваших конкретных потребностей и узнайте, как гибочный станок поможет повысить эффективность производства и качество продукции.
- Бесплатная консультация наших экспертов
- Решение под ваши задачи
- Выгодные цены и гибкая оплата
- Комплексное обучение и постоянная поддержка
- 5-Year Warranty
