Fiber Laser Cutting Machine -Open Type

General Features

Safe and beautiful design:

CNC Fiber Laser Cutting Machine High machining accuracy:
Equipped with high-torque servo motor and high-precision imported reducer, with high efficiency and good dynamic characteristics;
Good dynamics and cutting ability:
The high-rigidity welded body adopts aviation aluminum die-casting gantry, which improves the strength and weight of the gantry, and has good stability and durability;
Easy to operate and intelligent:
The professional digital control system developed by South Korea's MP company has realized the Hans digital control system with good performance, high reliability and easy operation.
Low operating cost:
Precise control to ensure low auxiliary gas consumption to ensure low operating costs. Three auxiliary gases can be freely selected by customers.

Why Choose BS3015D

BS3015D is a perfect standard plane fiber laser cutting machine, Safe and beautiful design,Suitable for sheet metal processing, kitchen appliances, sheet metal cabinets, lighting advertisements, electrical equipment and various metal products processing industries

Would you like the brochure ?

Check out the technical data sheet and machine details in our brochure

Optical fiber automatic focusing fiber cutting head NC30B

1. This cutting head has strong advantages in the application of medium-power large-format fiber laser cutting.

2. The internal structure of the laser head is completely sealed to prevent the optical part from being polluted by dust.

3. The laser head adopts two-point centering adjustment, and the focusing is driven by an imported motor, which is efficient in perforation

Significantly improved.

4. The protective lens is installed in a drawer type, which is easy to replace.

5. It can be equipped with various lasers with QBH connectors.

Laser Source

JPT single mode fiber laser(500W-2000W) is the optimal combination of optical, mechanical, electrical and software components. Through the controlling ports and the controlling software, the operating status of the laser can be monitored in real time, alarm messages can be received in time, and data can be collected. The laser uses water-cooling and shelf case design, with competitive advantage like high energy conversion (electric to light), low power consumption, maintenance free, fiber delivery, and easy to assemble, it is the most suitable laser source for industrial laser welding, cutting and other applications.

Yaskawa Reducer


High startability and short acceleration time; the reducer runs smoothly and has low noise;
Easy to install, save space and weight; reducer
Gears and racks can be adjusted to appropriate accuracy;
Good structure design, low moment of inertia;
The equipment can bear axial/radial thrust under heavy load;
The output shaft of the reducer is equipped with a set of high-strength rolling cone bearings;

YYC Gear From Taiwan

To meet the needs of mechanical equipment, YYC provides racks and pinions with different modules, which can completely replace linear transmission products such as ball screws, cylinders, and linear motors, and have an excellent cost performance.


Technical Parameters

1Machining area (Length *width)3000*1500mm4000*2000mm6000*2000mm
2X-axis stroke3020mm4020mm6020mm
3Y-axis stroke1520mm2020mm2020mm
4Z-axis stroke240mm150mm150mm
5Positioning precision of X/Y axis±0.03mm/m±0.03mm/m±0.03mm/m
6Repetitive positioning precision of X/Y axis±0.02mm±0.02mm±0.02mm
7Maximum speed120m/min100m/min120m/min
8Maximum Acceleration speed1.5G1.5G1.5G
9Tool weight2500KGS4500KGS6500KGS
10Maximum load of workbench1500KGS1000KGS1800KGS
11Laser Power2000W/3000W/4000W/6000W
12Dimension ( Length * Width* Height)4500*2400*13006100*3500*16008200*3200*2000
13Number of Phases333
14Rated voltage of power source380V380V380V
16Protection rating of main powerIP54IP54IP54
