Press Brake with ESTUN E300P CNC Controller | DurmaPress

DurmaPress hydraulic press brakes are available with the ESTUN E300P full-touch CNC controller — a new-generation control system developed by ESTUN Automation, one of China's leading CNC manufacturers. The E300P combines an intuitive touchscreen interface with advanced servo control technology, giving operators faster programming, higher bending accuracy, and reduced setup time.

1.What Is the ESTUN E300P CNC Controller?

E300P The full touch bending machine numerical control device is a new generation of CNC system for conventional bending machine developed and produced by ESTUN Automation Co. Ltd, The CNC adheres to the tradition of stable and reliable quality and superior performance of ESTUN CNC products, it integrates the advanced technology of delem，Optimized operation interface，The full touch operation mode is adopted to improve the operation convenience of customers,The control function of the machine tool is enhanced, and the working efficiency and machining accuracy of the machine tool are improved as a whole,The cost of electrical configuration of machine tool is reduced，It is a leading CNC control device for conventional bending machine in China.

The control function is improved and supports the servo axis control of X, Y and R axes，Two modes of crowing-axis hydraulic and mechanical.

Built in machine control logic，Logic free configuration of hydraulic valve group，I / O function ports are freely configured to simplify External circuit.

Accurate angle programming and calculation function, tools library and material table, improve the accuracy of angle calculation.

2.Key Features of the E300P Controller

The standard USB interface can backup of parameters and programs and online upgrade of system software.
ETS / Pronet series servo is equipped, with superior performance and stable quality.
Safety zone protection, collision detection, R-axis collision avoidance positioning function.
Built-in parameter backup and restore function to reduce service cost.
Resistive touch screen, stable and reliable, long work life.
Integrated housing, ergonomic design, convenient operation, beautiful and easy installation.
One-page programming, concise and clear， quick programming page, easy and fast operation.
Advanced CAN bus servo control technology is adopted, with simple wiring, fast positioning speed, and high precision.
10 " color LCD touch screen, which can be switched between Chinese and English, and two units of metric and British system are optional.

3.E300P Technical Specifications

Specification	Details
Screen	10" Color LCD Touch Screen
Controlled Axes	X, Y, R (CAN Bus)
Crowning Mode	Mechanical & Hydraulic
Language	Chinese / English
Unit System	Metric / Imperial
Interface	USB
Servo Series	ESTUN ETS / Pronet
Certification	ISO 9001

E300P Housing Combination

X, Y and R servo axes controlled by CAN bus
Crowing supports both mechanical and hydraulic modes
Built in machine work logic, multiple work modes
Tools library and material table
I / O ports are freely configurable
USB interface for backup and upgrade
parameter backup / restore function
Chinese / English Optional
Metric / imperial optional

ETS / Pronet Series Servo

Using the latest high-speed digital signal processor DSP,Advanced motion control software，Combined with feed forward control and command smoothing technology, the high response, high precision and high reliability of servo are truly realized.With the function of autom:

High speed, fast response, up to 3000 rpm
Stable quality and high reliability
Standard wiring, easy installation Can bus control, simple wiring and strong antiinterference ability

Electical Cabinet

Passed ISO9001 certification
High quality cabinet, Comply with EMC standards
The main components are imported or well-known brands
Adopt the most advanced electrical design software (E_ Plan) design
Advanced and reliable production and installation technology
It is manufactured by automatic assembly line

4.Compatible DurmaPress Press Brake Models

The ESTUN E300P controller is available on the following DurmaPress press brake series. Click to view full specifications and request a quote.

5.FAQ

Q1: What press brake axes does the E300P control?

A:The E300P controls X, Y, and R servo axes via CAN bus, supporting precise backgauge positioning and ram control for consistent bending results.

Q2: Is the E300P suitable for operators without CNC experience?

A:Yes. The one-page programming interface and touchscreen design are specifically developed to minimize the learning curve. Built-in tools and material tables further reduce the need for manual calculation.

Q3: Can the E300P system be upgraded or backed up?

A:Yes. The USB interface supports both parameter backup and online system software upgrades. A built-in parameter backup and restore function is also included to minimize downtime during servicing.

6.Request a Quote for DurmaPress Press Brake with E300P

Looking for a hydraulic press brake with the ESTUN E300P CNC controller? Contact DurmaPress today to discuss your requirements, including tonnage, working length, and tooling needs. Our team will respond within 24 hours.
