WQJ-400 Manual Profile Bending Machine -Main features

The WQJ-400 Manual Profile Bending Machine stands out as a reliable and efficient tool for bending steel and other materials with ease. Crafted with a steel welded construction frame, this machine ensures sturdy support for demanding bending tasks. Let's delve into its key features, standard configuration, and technical specifications that make it a valuable addition to any workshop.

Main Features

Steel Welded Construction Frame: The machine's robust frame provides the necessary strength and stability for precise bending operations, ensuring long-term durability.
Hardened Shafts: Crafted from special steel material, the hardened shafts offer exceptional resistance to wear and tear, enhancing the machine's lifespan and performance.
Hydraulic Top Roll: The top roll is hydraulically movable, allowing for convenient adjustments during operation to achieve the desired bending angles with precision.
Horizontal and Vertical Working Position: This machine offers the flexibility of both horizontal and vertical working positions, catering to a wide range of bending requirements.
Mobile Control Panel: The inclusion of a mobile control panel ensures ease of operation, allowing operators to adjust settings and control the machine from a convenient location.


Standard Configuration

  • Fixed Down Rollers: The two down rollers are fixed and serve as the main drivers for the bending process, providing stability and control.

  • Manual Vertical Movement: The up roller can be manually adjusted for vertical movement, giving operators the ability to fine-tune the bending process according to the material and requirements.

  • Foot Pedal Control: Featuring a foot pedal control with an emergency stop button, operators have a safe and efficient means of managing the bending operation.

  • Versatile Bending Capability: The machine is capable of bending a variety of materials including flat pieces, channel iron, pipes, and more, making it a versatile solution for different applications.

Technical Specifications

    • Up and Down Axis Diameter: 70mm
    • Up Mold Diameter: 120mm
    • Down Mold Diameter: 240mm
    • Minimum Bending Diameter: 300mm
    • Bending Speed: 5m/min.
    • Yield Limit: 245Mpa
    • Motor Power: 1.5KW
    • Dimensions: 800x760x1300mm (L x W x H)

The WQJ-400 Manual Profile Bending Machine combines durability, versatility, and precision, making it an ideal choice for workshops and manufacturing facilities. Whether bending flat pieces, channel iron, or pipes, this machine offers the features and performance needed to achieve accurate and efficient results. With its sturdy construction and user-friendly design, it stands as a reliable tool for various bending applications.
